Fire Pump Testing Bundles, Little Hose Monster
- Flow through the Little Hose Monster and 1 ¾” Pitotless Nozzle
- Our recommended setup for Fire Pump Testing
- Uses the Monster Tester for remote flow readings from a single gauge.
- Includes equipment case with custom-made foam insert for the Little Hose Monsters.
- For Special Thread specifications, please contact us at 888.202.9987
Please be advised that Gauge Calibrations require up to 48 hours.
|
Fire Pump Testing Bundle 750 – #FPTK750 (For up to 750 GPM Pump) 2 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 2 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 2 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 2 | 2.5″ x 25′ Hose |
| GK60D4 | 2 | Pressure Gauge, 0-60 PSI operating range, ¼” NPT, 0.5% accuracy FS |
| HMRR40 | 2 | Remote Reader Assembly, 40’ tube, 2-push to connect tube fittings |
| STK | 1 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 1 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
|
Fire Pump Testing Bundle 1000 – #FPTK1000 (For up to 1000 GPM Pump) 3 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 3 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 3 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 3 | 2.5″ x 25′ Hose |
| HMMT | 1 | Monster Tester with Tube Set and Gauge, 0 to 60 PSI, 0.5% accuracy rated |
| STK | 1 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 1 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
|
Fire Pump Testing Bundle 1500 – #FPTK1500 (For up to 1500 GPM Pump) 4 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 4 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 4 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 4 | 2.5″ x 25′ Hose |
| HMMT | 1 | Monster Tester with Tube Set and Gauge, 0 to 60 PSI, 0.5% accuracy rated |
| STK | 2 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 1 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
|
Fire Pump Testing Bundle 2000 – #FPTK2000 (For up to 2000 GPM Pump) 6 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 6 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 6 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 6 | 2.5″ x 25′ Hose |
| HMMT | 1 | Monster Tester with Tube Set and Gauge, 0 to 60 PSI, 0.5% accuracy rated |
| STK | 2 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 2 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
|
Fire Pump Testing Bundle 3000 – #FPTK3000 (For up to 3000 GPM Pump) 8 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 8 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 8 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 8 | 2.5″ x 25′ Hose |
| HMMT | 2 | Monster Tester with Tube Set and Gauge, 0 to 60 PSI, 0.5% accuracy rated |
| STK | 3 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 2 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
|
Fire Pump Testing Bundle 4000 – #FPTK4000 (For up to 4000 GPM Pump) 12 Hose Streams includes the following: |
||
| Item # | Qty | Description |
| HML | 12 | The Little Hose Monster™ – 10″ x 12″, for use with Pitotless Nozzle™ |
| PN1.75GRV | 12 | 1 ¾” Pitotless Nozzle FM Approved (337 to 1,011 GPM – per nozzle) |
| H2H.25 | 12 | 2.5″ x 25′ Hose |
| HMMT | 2 | Monster Tester with Tube Set and Gauge, 0 to 60 PSI, 0.5% accuracy rated |
| STK | 4 | Little Hose Monster Stabilizer For stacking HML, includes Tie Downs |
| WSPA106 | 1 | Spanner Wrench, Light weight aluminum alloy |
| CASERCFPT | 3 | Equipment Case, 27X19X10. Custom Insert for Little Hose Monsters |
Bundles are our recommended set-ups for Fire Pump Testing. Actual equipment needed may vary depending on intended use and preferences. Each component is sold as a separate line item and can be substituted. Contact us to determine the configuration best suited for your operation.
How many hose streams do I need?
- 2 Hose Streams can test a 750 GPM Rated Pump.
- 3 Hose Streams can test a 1000 GPM Rated Pump.
- 4 Hose Streams can test a 1500 GPM Rated Pump.
- 6 Hose Streams can test a 2000 GPM Rated Pump.
- 8 Hose Streams can test a 3000 GPM Rated Pump.
- 12 Hose Streams can test a 4000 GPM Rated Pump.
- Larger Pumps may require additional hose streams.
